Italian Esa Cnc 5 Axis Sawjet Water Jet Cutting Machine Waterjet machine

~~$90,000.00美元~~

Giảm giá Đã bán hết

Phí vận chuyển được tính khi thanh toán.

Type : CNC machine
Use : Stone processing
Production Capacity : High
Place of Origin : Fujian, China
Brand Name : Hualong
Power : 60.6KW
Dimension(L*W*H) : 6000x3820x3200mm
Weight : 10000 kg
Warranty : 1 Year
Key Selling Points : Multifunctional
Cutting thickness (max) : 100mm
Machinery Test Report : Provided
Video outgoing-inspection : Provided
Core Components : motor, Bearing, Gear, Gearbox, CNC system, Computer, Touch screen, Servo driver, Worm reducer, Linear guide, Helical gear rack, Hydraulic pump
Control system : CNC from Italy
Software : Italy Pegasus
Head rotation : 0-360°
Blade tilt : 0-90°
Waterjet cutting head rotation : 0-360°
Waterjet cutting head tilt : 0-60°
Worktable tilting degree : 85°
Guide Rail : Hiwin Linear Guide
Nesting : manual or automatic
Lubrication : manual or automatic
Showroom Location : None
Condition : New
Warranty of core components : 2 years
Applicable Industries : Building Material Shops, Construction works , Stone Processing
Marketing Type : Hot Product 2023

CNC Sawjet HKNC-400J

with top of the line Italian CNC control system ESA, is a fully automated dual-use machine, a combination of a 5-axis CNC saw and a 3-axis CNC waterjet, which is gone together constructing the revised concept system for cutting granite, marble, quarts, limestone and the rising new ceramic material.

CNC saw is used for cutting stone slabs, countertops and sinks, blade profiling, engraving and more.
The waterjet cutting head is perfect for cutting through different materials into precision intricate shapes and angles, ideal for cutting porcelain, stone, marble and granite inlay patterns.

Main Features

5-axis Saw --- this machine is a fully interpolated 5 axis bridge saw

* Automatic head rotation from 0° to 360° combined with automatic blade tilting from 0° to 90° makes it suitable for large production runs, at the same time containing costs.
* It can implement different complex curved surface processing and combines the functions of cutting, drilling, milling, engraving
into an oganic whole.

3-axis Waterjet ---this machine is a fully interpolated 3 axis waterjet either
* Automatic precise and fine cutting for
inside-corner or other complex design fabrication.
* KMT-H20 JET50 super-pressure pump equipped with Siemens PLC and motor.

1) 5 axis linkage control with Italian CNC Esa system.
2) Easy to use interface with 19" color touch-screen.
3) Y axis is moved by a gantry system, which guarantees a perfect square of the bridge
4) The absolute precision of the movements is guarantee by a state of art transmission on linear ball guide, moved by servo motors through high precision helical gears and racks.

5) CNC Sawjet & bridge saw can quickly do easy cuts in manual, the machine also can import and work with DXF (AutoCAD) files
6) Working platform can tilt 85 degrees, easy for slabs loading.
7) Photo slab for nesting and avoiding defects.
8) Nesting manual / automatic to optimize slab surface usage
9) RTCP tool point tracking function ensure precision machining easy.
10) Optional - Vein match for easily matching up perfectly each vein,color at the seam of your project.

TECHNICAL DATA FOR HKNC-400J
Diameter of saw blade	ø350-ø450	mm
Dimension of working platform	4150x2250	mm
X axis stroke	3500	mm
Y axis stroke	2000	mm
Z axis stroke	500	mm
Max. cutting thickness	100	mm
Max. lifting stroke	320	mm
Power of saw blade motor	26.4	kw
Power for abrasive waterjet	37	kw
Max. operating water pressure	450	mpa
Required pressure of inflow	0.4	mpa
Water consumption	11.4-16.7	l/min
Gross weight	10000	kg
Dimensions (L x W x H)	6000x3820x320	mm

Control system -- CNC

Brand: Esa

Original: Italy
Top of the line CNC system with touch screen for easy setting and automatic processing. It can make a complicated machining job
easy, perfect and high efficient.

Software - Pegasus CAD/CAM

Brand: Pegasus

Original: Italy

* Easy to Use -- Very user-friendly, it does not require any advanced computer skill.
* Reliable -- Frequent updates and high-quality support.
* Powerful -- Different modules and tools for plenty of technologies and machinings.

Slab Image Capture (Optional)

The application allows to acquire and process the slab photo, by correcting the lens distortion and rectifying it. Through the
acquired image, the shapes can be arranged on the slab avoiding material imperfections while identifying the nervures that need to
be machined; it is also possible to qualify the slab edge geometrically.

Digital Servomotor

Brand: YASKAWA

Original: Japan

A permanent magnet servomotor with intergrated drives, well matching with Esa’s CNCs, creates a reliable controlling power for X, Y, Z, C and A axises

Electro-spindles

of high quality controlled by an inverter allowing the adjustment of the nr. of revolutions from 0 to 6000 rpm, so
granting the use of blade and diamond tools such as a core drill or milling cutter. The tool change is of manual type.
Internal water passage

Electric Cabinet

Branded electric companets such ESA, Schneider, Yaskawa, Sanch are adopted to ensure stable performance.
